AC Fans 17cm ~ 18cm
AA1740M9L SERIES
- Size: 172 x 150 x 38mm
- Housing: Aluminum
- Impeller: Metal
- Motor: AC Induction Capacitor With External Motor
- Operating Temperature: -10°C ~ +105°C
- Insulation: Class B
- Housing: Aluminum
- Impeller: Metal
- Motor: AC Induction Capacitor With External Motor
- Operating Temperature: -10°C ~ +105°C
- Insulation: Class B
Download PDF
AA1740M9L SERIES (2020)
|
Model Number |
Voltage |
Frequency |
Current |
Power |
Speed |
Air Flow |
Noise |
|
(V) |
(Hz) |
(A) |
(W) |
(RPM) |
(CFM) |
dB(A) |
|
|
AA1740V11MBH*9L |
100/125 |
50/60 |
0.25/0.25 |
32 |
2500/2900 |
214/250 |
56/59 |
|
AA1740V22MBH*9L |
200/240 |
50/60 |
0.14/0.14 |
32 |
2500/2900 |
214/250 |
56/29 |
* for T/W = Terminals/ Lead Wires
