- Housing: Aluminum
- Impeller: Aluminum
- Motor: AC Shaded Pole Type
- Operating Temperature: -30°C ~ +70°C
- Insulation: Class B
|
Model Number |
Voltage |
Frequency |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(Hz) |
(A) |
(W) |
(RPM) |
(CFM) |
(mmH2O) |
dB(A) |
|
|
AA17251V11_N*YY5 |
115 |
50/60 |
0.22/0.23 |
25/27 |
2800/3200 |
203/239 |
17.1/18.8 |
51/58 |
|
AA17251V11_H*YY5 |
115 |
50/60 |
0.50/0.45 |
37/36 |
2700/3100 |
190/235 |
16.0/17.7 |
45/50 |
|
AA17251V11_M*YY5 |
115 |
50/60 |
0.41/0.39 |
32/30 |
2400/2300 |
170/160 |
15.0/14.0 |
41/40 |
|
AA17251V11_L*YY5 |
115 |
50/60 |
0.35/0.35 |
26/25 |
1900/1500 |
125/105 |
8.0/6.0 |
32/30 |
|
AA17251V22_N*YY5 |
220 |
50/60 |
0.11/0.11 |
25/26 |
2800/3200 |
203/239 |
17.1/18.8 |
51/58 |
|
AA17251V22_H*YY5 |
220 |
50/60 |
0.22/0.21 |
34/33 |
2700/3100 |
190/235 |
16.0/17.7 |
45/50 |
|
AA17251V22_M*YY5 |
220 |
50/60 |
0.19/0.18 |
30/28 |
2400/2300 |
170/160 |
15.0/14.0 |
41/40 |
|
AA17251V22_L*YY5 |
220 |
50/60 |
0.16/0.16 |
26/25 |
1900/1500 |
125/105 |
8.0/6.0 |
32/30 |
|
AA17251V38_N*YY5 |
380 |
50 |
0.06 |
20 |
2800 |
203 |
17.1 |
51 |
|
AA17251V38_H*YY5 |
380 |
50 |
0.11 |
34 |
2700 |
190 |
16.0 |
45 |
|
AA17251V38_M*YY5 |
380 |
50 |
0.09 |
30 |
2400 |
170 |
15.0 |
41 |
|
AA17251V38_L*YY5 |
380 |
50 |
0.07 |
26 |
1900 |
125 |
8.0 |
32 |
_ for B / S = Ball Bearing / Sleeve Bearing,
* for T/W = Terminals/ Lead Wires
