AC Fans 20cm ~ 25cm
AA22080M9L SERIES
- Size: 200 x 200 x 80mm
- Housing: Aluminum
- Impeller: Metal
- Motor: AC Capacitor Motor with External Rotor
- Operating Temperature: -10°C ~ +105°C
- Insulation: Class E
- Housing: Aluminum
- Impeller: Metal
- Motor: AC Capacitor Motor with External Rotor
- Operating Temperature: -10°C ~ +105°C
- Insulation: Class E
Download PDF
AA22080M9L SERIES (2020)
|
Model Number |
Voltage |
Frequency |
Current |
Power |
Speed |
Air Flow |
Noise |
|
(V) |
(Hz) |
(A) |
(W) |
(RPM) |
(CFM) |
dB(A) |
|
|
AA22080V11MBH*9L |
100/125 |
50/60 |
0.58/0.65 |
67/77 |
2600/2800 |
500/545 |
59/61 |
|
AA22080V22MBH*9L |
200/240 |
50/60 |
0.28/0.35 |
62/80 |
2600/2800 |
500/545 |
59/61 |
|
AA22080V38MBH*9L |
380/420 |
50/60 |
0.25 |
65 |
2600/2800 |
500/545 |
59/61 |
* for T/W = Terminals/ Lead Wires
