AC Fans 20cm ~ 25cm
AA25489 SERIES
- Size: Φ254 x 89mm
- Housing: Aluminum
- Impeller: Thermoplastic PBT, UL94V-0
- Motor: AC Capacitor Motor with External Rotor
- Operating Temperature: -10°C ~ + 70°C
- Insulation: Class B/F
- Housing: Aluminum
- Impeller: Thermoplastic PBT, UL94V-0
- Motor: AC Capacitor Motor with External Rotor
- Operating Temperature: -10°C ~ + 70°C
- Insulation: Class B/F
Download PDF
AA25489 SERIES (2020)
|
Model Number |
Voltage |
Frequency |
Current |
Power |
Speed |
Air Flow |
Noise |
|
(V) |
(Hz) |
(A) |
(W) |
(RPM) |
(CFM) |
dB(A) |
|
|
AA25489V11BH* |
115 |
50/60 |
0.35/0.36 |
38/40 |
1400/1700 |
443/525 |
49/53 |
|
AA25489V22BH* |
230 |
50/60 |
0.19/0.18 |
39/40 |
1400/1700 |
445/529 |
49/53 |
* for T/W = Terminals/ Lead Wires
