Products
- Housing: Plastic (UL 94V-0)
- Impeller: Plastic (UL 94V-0)
- Motor: 4 Pole Brushless DC Motor
- Operating Temperature: -10°C ~ +70°C
- Insulation: Class A
- Weight: 260.0g
|
Model Number |
Voltage |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(A) |
(W) |
(RPM) |
(CFM) |
(inH2O) |
dB(A) |
|
|
① AD1238V12_MWGE |
12 |
0.18 |
2.16 |
2300 |
101.4 |
0.32 |
38 |
|
① AD1238V24_LWGE |
24 |
0.14 |
3.36 |
2300 |
101.4 |
0.32 |
38 |
|
① AD1238V48_IWGE |
48 |
0.10 |
4.80 |
2300 |
101.4 |
0.32 |
38 |
|
② AD1238V12_HWGE |
12 |
0.40 |
4.80 |
2600 |
114.7 |
0.41 |
41 |
|
② AD1238V24_MWGE |
24 |
0.30 |
7.20 |
2600 |
114.7 |
0.41 |
41 |
|
② AD1238V48BJWGE |
48 |
0.14 |
6.72 |
2600 |
114.7 |
0.41 |
41 |
|
③ AD1238V12BUWGE |
12 |
0.75 |
9.00 |
2900 |
123.2 |
0.45 |
44 |
|
③ AD1238V24BHWGE |
24 |
0.48 |
11.52 |
2900 |
123.2 |
0.45 |
44 |
|
③ AD1238V48BLWGE |
48 |
0.25 |
12.00 |
2900 |
123.2 |
0.45 |
44 |
|
④ AD1238V12BVWGE |
12 |
0.80 |
9.60 |
3200 |
135.9 |
0.54 |
48 |
|
④ AD1238V24BUWGE |
24 |
0.62 |
14.88 |
3200 |
135.9 |
0.54 |
48 |
|
④ AD1238V48BMWGE |
48 |
0.30 |
14.40 |
3200 |
135.9 |
0.54 |
48 |
|
⑤ AD1238V12BWWGE |
12 |
1.55 |
18.60 |
4200 |
178.4 |
0.94 |
54 |
|
⑤ AD1238V24BVWGE |
24 |
0.85 |
20.40 |
4200 |
178.4 |
0.94 |
54 |
|
⑤ AD1238V48BHWGE |
48 |
0.48 |
23.04 |
4200 |
178.4 |
0.94 |
54 |
_ for B / F = Ball Bearing / Fluid Bearing
