DC Fans 2cm ~5cm
AD3820GE SERIES
- Size: 38 x 38 x 20mm
- Housing: Plastic (UL 94V-0)
- Impeller: Plastic (UL 94V-0)
- Motor: 4 Pole Brushless DC Motor
- Operating Temperature: -10°C ~ +70°C
- Insulation: Class A
- Weight: 31.0g
- Housing: Plastic (UL 94V-0)
- Impeller: Plastic (UL 94V-0)
- Motor: 4 Pole Brushless DC Motor
- Operating Temperature: -10°C ~ +70°C
- Insulation: Class A
- Weight: 31.0g
Download PDF
AD3820GE SERIES (2020)
|
Model Number |
Voltage |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(A) |
(W) |
(RPM) |
(CFM) |
(inH2O) |
dB(A) |
|
|
① AD3820V12BLWGE |
12 |
0.10 |
1.20 |
6700 |
6.3 |
0.22 |
36 |
|
① AD3820V24BLWGE |
24 |
0.07 |
1.68 |
6700 |
6.3 |
0.22 |
36 |
|
② AD3820V12BMWGE |
12 |
0.12 |
1.44 |
8000 |
7.4 |
0.34 |
40 |
|
② AD3820V24BMWGE |
24 |
0.07 |
1.68 |
8000 |
7.4 |
0.34 |
40 |
|
③ AD3820V12BHWGE |
12 |
0.13 |
1.56 |
8900 |
8.6 |
0.39 |
42 |
|
③ AD3820V24BHWGE |
24 |
0.09 |
2.16 |
8900 |
8.6 |
0.39 |
42 |
|
④ AD3820V12BUWGE |
12 |
0.30 |
3.60 |
10000 |
10.6 |
0.58 |
43 |
|
④ AD3820V24BUWGE |
24 |
0.17 |
4.08 |
10000 |
10.6 |
0.58 |
43 |
B = Ball Bearing
