- Housing: Plastic (UL 94V-0)
- Impeller: Plastic (UL 94V-0)
- Motor: 4 Pole Brushless DC Motor
- Operating Temperature: -10°C ~ +70°C
- Insulation: Class A
- Weight: 210.0g
|
Model Number |
Voltage |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(A) |
(W) |
(RPM) |
(CFM) |
(inH2O) |
dB(A) |
|
|
① AD8038V12BLWGB |
12 |
0.40 |
4.80 |
4200 |
58.2 |
0.41 |
45 |
|
① AD8038V24BLWGB |
24 |
0.25 |
6.00 |
4200 |
58.2 |
0.41 |
45 |
|
① AD8038V48BLWGB |
48 |
0.23 |
11.04 |
4200 |
58.2 |
0.41 |
45 |
|
② AD8038V12BMWGB |
12 |
0.76 |
9.12 |
5600 |
78.8 |
0.76 |
53 |
|
② AD8038V24BMWGB |
24 |
0.35 |
8.40 |
5600 |
78.8 |
0.76 |
53 |
|
② AD8038V48BMWGB |
48 |
0.33 |
15.84 |
5600 |
78.8 |
0.76 |
53 |
|
③ AD8038V12BHWGB |
12 |
1.00 |
12.00 |
6100 |
84.8 |
0.89 |
56 |
|
③ AD8038V24BHWGB |
24 |
0.45 |
10.80 |
6100 |
84.8 |
0.89 |
56 |
|
③ AD8038V48BHWGB |
48 |
0.51 |
24.48 |
6100 |
84.8 |
0.89 |
56 |
|
④ AD8038V12BUWGB |
12 |
1.50 |
18.00 |
7500 |
105.5 |
1.36 |
62 |
|
④ AD8038V24BUWGB |
24 |
0.82 |
19.68 |
7500 |
105.5 |
1.36 |
62 |
|
④ AD8038V48BUWGB |
48 |
0.58 |
27.84 |
7500 |
105.5 |
1.36 |
62 |
|
⑤ AD8038V12BVWGB |
12 |
2.70 |
32.40 |
9000 |
130.0 |
2.00 |
66 |
|
⑤ AD8038V24BVWGB |
24 |
1.40 |
33.60 |
9000 |
130.0 |
2.00 |
66 |
|
⑤ AD8038V48BVWGB |
48 |
0.96 |
46.08 |
9000 |
130.0 |
2.00 |
66 |
B = Ball Bearing
