Products
- Housing: Plastic (UL 94V-0)
- Impeller: Plastic (UL 94V-0)
- Motor: 4 Pole Brushless DC Motor
- Operating Temperature: -10°C ~ +70°C
- Insulation: Class A
- Weight: 89.0g
|
Model Number |
Voltage |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(A) |
(W) |
(RPM) |
(CFM) |
(inH2O) |
dB(A) |
|
|
① AD9225V12_JWGC |
12 |
0.09 |
1.08 |
2100 |
39.2 |
0.09 |
25 |
|
① AD9225V24_JWGC |
24 |
0.06 |
1.44 |
2100 |
39.2 |
0.09 |
25 |
|
① AD9225V48_JWGC |
48 |
0.50 |
24.00 |
2100 |
39.2 |
0.09 |
25 |
|
② AD9225V12_LWGC |
12 |
0.11 |
1.32 |
2450 |
44.8 |
0.12 |
30 |
|
② AD9225V24_LWGC |
24 |
0.08 |
1.92 |
2450 |
44.8 |
0.12 |
30 |
|
② AD9225V48_LWGC |
48 |
0.06 |
2.88 |
2450 |
44.8 |
0.12 |
30 |
|
③ AD9225V12_MWGC |
12 |
0.14 |
1.68 |
2850 |
52.1 |
0.17 |
34 |
|
③ AD9225V24_MWGC |
24 |
0.13 |
3.12 |
2850 |
52.1 |
0.17 |
34 |
|
③ AD9225V48_MWGC |
48 |
0.08 |
3.84 |
2850 |
52.1 |
0.17 |
34 |
|
④ AD9225V12_HWGC |
12 |
0.20 |
2.40 |
3200 |
58.3 |
0.22 |
38 |
|
④ AD9225V24_HWGC |
24 |
0.15 |
3.60 |
3200 |
58.3 |
0.22 |
38 |
|
④ AD9225V48_HWGC |
48 |
0.12 |
5.76 |
3200 |
58.3 |
0.22 |
38 |
|
⑤ AD9225V12_UWGC |
12 |
0.30 |
3.60 |
3800 |
69.2 |
0.28 |
45 |
|
⑤ AD9225V24_UWGC |
24 |
0.20 |
4.80 |
3800 |
69.2 |
0.28 |
45 |
|
⑤ AD9225V48_UWGC |
48 |
0.15 |
7.20 |
3800 |
69.2 |
0.28 |
45 |
|
⑥ AD9225V12_VWGC |
12 |
0.41 |
4.92 |
4500 |
81.0 |
0.40 |
49 |
_ for B / F = Ball Bearing / Fluid Bearing
