- Housing: Plastic (UL 94V-0)
- Impeller: Plastic (UL 94V-0)
- Motor: 4 Pole Brushless DC Motor
- Operating Temperature: -10°C ~ +70°C
- Insulation: Class A
- Weight: 200.0g
|
Model Number |
Voltage |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(A) |
(W) |
(RPM) |
(CFM) |
(inH2O) |
dB(A) |
|
|
① AD9238V12BLWGB |
12 |
0.50 |
6.00 |
4300 |
97.1 |
0.70 |
52 |
|
① AD9238V24BLWGB |
24 |
0.35 |
8.40 |
4300 |
97.1 |
0.70 |
52 |
|
① AD9238V48BLWGB |
48 |
0.24 |
11.52 |
4300 |
97.1 |
0.70 |
52 |
|
② AD9238V12BMWGB |
12 |
0.96 |
11.52 |
5000 |
109.2 |
0.86 |
58 |
|
② AD9238V24BMWGB |
24 |
0.45 |
10.80 |
5000 |
109.2 |
0.86 |
58 |
|
② AD9238V48BMWGB |
48 |
0.28 |
13.44 |
5000 |
109.2 |
0.86 |
58 |
|
③ AD9238V12BHWGB |
12 |
1.20 |
14.40 |
6000 |
123.4 |
1.12 |
64 |
|
③ AD9238V24BHWGB |
24 |
0.76 |
18.24 |
6000 |
123.4 |
1.12 |
64 |
|
③ AD9238V48BHWGB |
48 |
0.41 |
19.68 |
6000 |
123.4 |
1.12 |
64 |
|
④ AD9238V12BUWGB |
12 |
2.50 |
30.00 |
7000 |
145.6 |
1.46 |
67 |
|
④ AD9238V24BUWGB |
24 |
1.10 |
26.40 |
6000 |
145.6 |
1.46 |
67 |
|
④ AD9238V48BUWGB |
48 |
0.72 |
34.56 |
7000 |
145.6 |
1.46 |
67 |
|
⑤ AD9238V12BVWGB |
12 |
2.95 |
35.40 |
8000 |
166.4 |
1.91 |
72 |
|
⑤ AD9238V24BVWGB |
24 |
1.70 |
40.80 |
8000 |
166.4 |
1.91 |
72 |
|
⑤ AD9238V48BVWGB |
48 |
0.94 |
45.12 |
8000 |
166.4 |
1.91 |
72 |
B = Ball Bearing
